Regulator module 9v to 5v
π 9V to 5V Regulator Module β DC-DC Buck Converter
This compact Regulator Module efficiently steps down 9V (or higher) input voltage to a stable 5V DC output, making it perfect for powering Arduino boards, ESP8266/ESP32, sensors, and USB-powered devices. Based on a DC-DC buck converter design, it is energy-efficient and provides consistent output voltage even under varying input.
βοΈ Technical Specifications
| Parameter | Specification |
|---|---|
| Input Voltage | 6V β 24V DC (Recommended: 9V β 12V) |
| Output Voltage | 5V DC (regulated) |
| Max Output Current | 2A (with heatsink or good ventilation) |
| Conversion Type | Buck (Step-Down) |
| Efficiency | Up to 95% |
| Output Connector | 3-pin header or USB (depends on version) |
| Dimensions | ~3 cm x 1.7 cm |
β Features
π Stable 5V output β great for microcontrollers and USB devices
βοΈ Wide input range β accepts from 6V up to 24V
π§° Easy to integrate into Arduino, Raspberry Pi, and DIY circuits
π‘οΈ Built-in protection against overheat, overload, and short circuits
β‘ High efficiency with low power loss
π§ͺ Typical Uses
Powering 5V sensors and modules from 9V batteries
Supplying 5V to Arduino Uno, Nano, ESP32, etc.
Regulating voltage for breadboard or prototype circuits
USB device charging (if module has USB output)
Robotics and portable electronics
π οΈ Example Connection
| Regulator Pin | Connect To |
|---|---|
| VIN | 9V battery (+) |
| GND | Battery (β) |
| VOUT | To 5V device |
π‘ You can add a filter capacitor (e.g., 470ΞΌF) across the input/output for extra stability.
